Fiber Laser Cutting Machine

Fiber Laser Cutting Machine
Fiber Laser Cutting Machine
Send Inquiry
Product Code : RD-CF2513A
Brand Name : Radar Laser
Product Description
Fiber Laser Cutting Machine (RD-CF2513A)
  1. Fiber laser cutting machine series adopt fiber laser generator ,the output energy is very high and dense ,the laser is guided by fiber ,then focused by imported mirror and concentrated onto workpiece surface to melt and gasify the cutting area ,the machine can automatically cut by computer control.
  2. Top class laser generator in the world, performance steady ,using life time 100,000 hours.
  3. Imported servo motor and accelerator , high precision ball screw transmission guiding track ,sealed protective device and oil system, all these can make the cutting precision ,using life and function to the best.
  4. USA imported cutting head and controlling technology, make operation more safe ,convenient and perfect.
Technical parameters
  • Model No. - RD-CF2513A, RD-CF3015, RD-CF4020
  • Max. laser power - 300W / 500W / 1000W (optional)
  • Wave length - 1064nm
  • Cutting line width - 0.15mm / 0.2mm / 0.2mm
  • Relocation accuracy - ±0.05mm
  • Cutting speed - according to material and thickness
  • Working size(mm) - 1300X2500 / 1500X3000 / 2000X4000
  • Whole power consumed - 10KW
  • Working voltage - AC 380V 50Hz
  • Cooling type - water cooling
  • Device weight - 3.2T/ 3.5T/ 4T
  • Main body dimension - 4420*2340*1700 / 4920*2540*1700 / 5920*3050*1700 according to the actual working size
  • Cooling system dimension - 720*510*770
